M20-8770642
Pin Header, Vertical, Board-to-Board, 2.54 mm, 1 Rows, 6 Contacts, Surface Mount Straight, M20-87
936 In Stock
Need more?
936 Delivery in 3-4 Business Days(UK stock)
| Quantity | Price (inc GST) |
|---|---|
| 10+ | S$0.627 (S$0.6834) |
| 100+ | S$0.534 (S$0.5821) |
| 500+ | S$0.477 (S$0.5199) |
| 1000+ | S$0.450 (S$0.4905) |
| 2500+ | S$0.432 (S$0.4709) |
| 5000+ | S$0.413 (S$0.4502) |
Price for:Each
Minimum: 10
Multiple: 10
S$6.27 (S$6.83 inc GST)
Line Note
Added to your Order Confirmation, Invoice, and Dispatch note for this order only.
Product Information
ManufacturerHARWIN
Manufacturer Part NoM20-8770642Copy
Manufacturer Standard Lead Time16 weeks
Order Code1517384
Product RangeM20-87
Connector SystemsBoard-to-Board
Pitch Spacing2.54mm
No. of Rows1Rows
No. of Contacts6Contacts
Contact Termination TypeSurface Mount Straight
Product RangeM20-87
Connector ShroudUnshrouded
Contact MaterialBrass
Contact PlatingGold Plated Contacts
Connector TypePin Header
SVHCNo SVHC (04-Feb-2026)
Product Overview
The M20-8770642 is a 6-way 1-row Vertical Pin Header with gold-plated brass contacts, polyamide (nylon) 6T housing, 2.54mm pitch spacing. Suitable for use with female connectors and jumper sockets.
- Surface mount
Applications
Industrial, Commercial
Technical Specifications
Connector Systems
Board-to-Board
No. of Rows
1Rows
Contact Termination Type
Surface Mount Straight
Connector Shroud
Unshrouded
Contact Plating
Gold Plated Contacts
SVHC
No SVHC (04-Feb-2026)
Pitch Spacing
2.54mm
No. of Contacts
6Contacts
Product Range
M20-87
Contact Material
Brass
Connector Type
Pin Header
Technical Docs (3)
Alternatives for M20-8770642
3 Products Found
Associated Products
2 Products Found
Legislation and Environmental
Country of Origin:
Country in which last significant manufacturing process was carried outCountry of Origin:Taiwan
Country in which last significant manufacturing process was carried out
Country in which last significant manufacturing process was carried outCountry of Origin:Taiwan
Country in which last significant manufacturing process was carried out
Tariff No:85389099
US ECCN:EAR99
EU ECCN:NLR
RoHS Compliant:Yes
RoHS
RoHS Phthalates Compliant:Yes
RoHS
SVHC:No SVHC (04-Feb-2026)
Download Product Compliance Certificate
Product Compliance Certificate
Weight (kg):.00035
