| Manufacturer | ANALOG DEVICES |
|---|---|
| Manufacturer Part No | LTM4662IY#PBFCopy |
| Manufacturer Standard Lead Time | 52 weeks |
| Order Code | 4033696 |
| Product Range | LTM4662 Series |
| Your Part Number | |
| Technical Datasheet |
Notify me when back in stock
| Quantity | Price (inc GST) |
|---|---|
| 1+ | S$100.380 (S$109.4142) |
| 10+ | S$95.080 (S$103.6372) |
| 25+ | S$93.040 (S$101.4136) |
| 112+ | S$89.790 (S$97.8711) |
Product Information
| Manufacturer | ANALOG DEVICES |
|---|---|
| Manufacturer Part No | LTM4662IY#PBFCopy |
| Manufacturer Standard Lead Time | 52 weeks |
| Order Code | 4033696 |
| Product Range | LTM4662 Series |
| Technical Datasheet | |
| Power Supply Applications | ITE, Industrial & Medical |
| Input Voltage Min | 2.375V |
| DC / DC Converter Type | BGA-88, Micro Module |
| Output Power Max | - |
| Input Voltage Max | 20V |
| No. of Outputs | 2 Output |
| Output Voltage Min | 600mV |
| Output Voltage Max | 5.5V |
| DC / DC Converter IC Case | BGA |
| No. of Pins | 88Pins |
| Output Current Max | 30A |
| Output Current | 15A |
| DC / DC Converter Output Type | Adjustable |
| Input Voltage DC Min | 4.5V |
| Input Voltage DC Max | 20V |
| Switching Frequency | 1MHz |
| Height | 5.74mm |
| Topology | Buck (Step Down) |
| Depth | 15mm |
| Operating Temperature Max | 125°C |
| Width | 11.25mm |
| Product Range | LTM4662 Series |
| MSL | MSL 3 - 168 hours |
| SVHC | Lead (04-Feb-2026) |
Product Overview
LTM4662 is a complete dual 15A output switching mode DC/DC power supply. Included in the package are the switching controller, power FETs, inductors, and all supporting components. Its high efficiency design delivers upto 15A continuous current for each output. Only a few input and output capacitors are needed. This device supports frequency synchronization, multiphase operation, high efficiency light load operation and output voltage tracking for supply rail sequencing and has an onboard temperature diode per channel for device temperature monitoring. High switching frequency and a current mode architecture enable a very fast transient response to line and load changes without sacrificing stability. It is used in applications such as point-of-load power supplies, telecom and networking equipment, industrial and medical equipment etc.
- Wide input voltage range from 4.5V to 20V
- Input DC voltage from 2.375V to 20V
- Output voltage range from 0.6V to 5.5V
- ±1.5% maximum total DC output error, multiphase current sharing
- Differential remote sense amplifier, each channel, current mode control/fast transient response
- Frequency synchronization, overcurrent foldback protection
- Output overvoltage protection, internal or external compensation
- Built-in temperature monitor diode, pin-compatible with the LTM4646
- Frequency sync capture range from 250KHz to 1000KHz
- Operating temperature range from -40°C to 125°C, package style is 88-lead BGA
Notes
ADI products are only authorized (and sold) for use by the customer and are not to be resold or otherwise passed on to any third party
Technical Specifications
| Power Supply Applications | ITE, Industrial & Medical |
|---|---|
| DC / DC Converter Type | BGA-88, Micro Module |
| Input Voltage Max | 20V |
| Output Voltage Min | 600mV |
| DC / DC Converter IC Case | BGA |
| Output Current Max | 30A |
| DC / DC Converter Output Type | Adjustable |
| Input Voltage DC Max | 20V |
| Height | 5.74mm |
| Depth | 15mm |
| Width | 11.25mm |
| MSL | MSL 3 - 168 hours |
| Input Voltage Min | 2.375V |
|---|---|
| Output Power Max | - |
| No. of Outputs | 2 Output |
| Output Voltage Max | 5.5V |
| No. of Pins | 88Pins |
| Output Current | 15A |
| Input Voltage DC Min | 4.5V |
| Switching Frequency | 1MHz |
| Topology | Buck (Step Down) |
| Operating Temperature Max | 125°C |
| Product Range | LTM4662 Series |
| SVHC | Lead (04-Feb-2026) |
Technical Docs (1)
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | Malaysia Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85423990 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Y-Ex RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | Lead (04-Feb-2026) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .010419 |
