MAX32670EVKIT#

MAX32670EVKIT# is an evaluation kit (EV kit) that provides a platform for evaluation capabilities of the MAX32670. The MAX32670 is an ultra-low-power, cost-effective, highly reliable 32bit microcontroller that enables designs with complex sensor processing without compromising battery life. It combines a flexible and versatile power management unit with the powerful Arm® Cortex® -M4 core with floating point unit (FPU). The MAX32670 also offers legacy designs an easy and cost optimal upgrade path from 8-bit or 16-bit microcontrollers.

• USB 2.0 Micro B to serial UART bridge
• UART0 and UART3 interface is selectable through on-board jumpers
• On-board MAX32625PICO-based debugger
• Boot load enable circuitry
• SPI and I2C signals accessed through 0.1in headers
• GPIOs and miscellaneous signals accessed through 0.1in headers
• Board power provided by USB port
• On-board SIMO regulator and LDO for IC and peripherals
• Individual power measurement on all IC rails through jumpers
• Two general-purpose LED and one general- purpose pushbutton switch

Contents

MAX32670 EV kit containing a MAX32670, One standard A to Micro B USB cable.

Notes

ADI products are only authorized (and sold) for use by the customer and are not to be resold or otherwise passed on to any third party
