Product Information
| Manufacturer | ARIES |
|---|---|
| Manufacturer Part No | 20-3518-10Copy |
| Manufacturer Standard Lead Time | 11 weeks |
| Order Code | 1674788 |
| Product Range | 518 |
| Technical Datasheet | |
| No. of Contacts | 20Contacts |
| Connector Type | DIP |
| Pitch Spacing | 2.54mm |
| Product Range | 518 |
| Row Pitch | 7.62mm |
| Contact Material | Beryllium Copper |
| Contact Plating | Gold Plated Contacts |
Product Overview
The 20-3518-10 is a 20-contact black Open Frame Socket with collet contacts and surface mount pins. This 518 series socket with gold-plated beryllium copper contacts, UL94V-0 Glass-filled 4/6 nylon body. Open frame allows for more efficient utilization of board space and better cooling.
- 3A Contact current rating
- Compatible with automatic insertion equipment
- Side-to-side and end-to-end stackable
Applications
Industrial
Technical Specifications
| No. of Contacts | 20Contacts |
|---|---|
| Pitch Spacing | 2.54mm |
| Row Pitch | 7.62mm |
| Contact Plating | Gold Plated Contacts |
| Connector Type | DIP |
|---|---|
| Product Range | 518 |
| Contact Material | Beryllium Copper |
Technical Docs (1)
Alternatives for 20-3518-10
4 Products Found
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | United States Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85366930 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .002 |
