HEDS-9830DPEVB
Evaluation Kit, AEDR-9830DP, Incremental Encoder, 318 LPI Evaluation Board and Code Wheel
| Manufacturer | BROADCOM |
|---|---|
| Manufacturer Part No | HEDS-9830DPEVBCopy |
| Manufacturer Standard Lead Time | 18 weeks |
| Order Code | 4626769 |
| Your Part Number | |
| Technical Datasheet |
Need more?
| Quantity | Price (inc GST) |
|---|---|
| 1+ | S$99.260 (S$108.1934) |
Product Information
| Manufacturer | BROADCOM |
|---|---|
| Manufacturer Part No | HEDS-9830DPEVBCopy |
| Manufacturer Standard Lead Time | 18 weeks |
| Order Code | 4626769 |
| Technical Datasheet | |
| Board Type | Evaluation Board |
| IC / Module Used | AEDR-9830DP |
| Application Sub Type | Incremental Encoder |
| Kit Contents | Evaluation Board AEDR-9830DP, Code Wheel Set |
| SVHC | No SVHC (07-Nov-2024) |
Product Overview
HEDS-9830DPEVB is an AEDR-9830DP evaluation board 318 LPI evaluation board and code wheel. The AEDR-9830DP is a three-channel reflective optical encoder. It can be configured to analogue or digital outputs employing reflective technology for motion control purposes. The AEDR-9830DP in analogue encoder modes with two-channel differential analogue outputs (Sin, /Sin, Cos,/Cos), can be interfaced directly, with external interpolators available. The AEDR-9830DP in digital encoder mode offers two-channel (AB) quadrature digital outputs and a third channel digital index output. Suitable for closed-loop stepper motors, small motors, actuators, industrial printers, robotics, card readers, pan-tilt-zoom (PTZ) cameras, portable medical equipment, optometric equipment and linear stages applications.
- Built-in interpolator for 1x, 2x, 4x, 8x, and 16x interpolation
- Surface-mount leadless package: 4mm (L) x 4mm (W) x 0.73mm (H)
- Operating voltage of 3.3V and 5.0V supply
- Built-in LED current regulation
- Wide operating temperature range from -40°C to +115°C
- Translucent protection compound
- High encoding resolution: 318 LPI (lines per in.) or 12.52 LPmm (lines per mm)
Technical Specifications
| Board Type | Evaluation Board |
|---|---|
| Application Sub Type | Incremental Encoder |
| SVHC | No SVHC (07-Nov-2024) |
| IC / Module Used | AEDR-9830DP |
|---|---|
| Kit Contents | Evaluation Board AEDR-9830DP, Code Wheel Set |
Technical Docs (1)
Legislation and Environmental
| Country of Origin: Country in which last significant manufacturing process was carried outCountry of Origin: | Malaysia Country in which last significant manufacturing process was carried out |
|---|---|
| Tariff No: | 85437090 |
| US ECCN: | EAR99 |
| EU ECCN: | NLR |
| RoHS Compliant: | Yes RoHS |
| RoHS Phthalates Compliant: | Yes RoHS |
| SVHC: | No SVHC (07-Nov-2024) |
| Download Product Compliance Certificate | Product Compliance Certificate |
| Weight (kg): | .000001 |
