1650780000

Heavy Duty Connector, Insert, HA Series, Cable Mount, Receptacle, 16 Contacts, Socket, 2 Rows

1650780000 - Heavy Duty Connector, Insert, HA Series, Cable Mount, Receptacle, 16 Contacts, Socket, 2 Rows

Image is for illustrative purposes only. Please refer to product description.

Manufacturer Part No:
1650780000
Order Code:
1361604
Product Range
HA Series
Also Known As:
HDC HA 16 FS
Technical Datasheet:
1650780000   Datasheet
See all Technical Docs

Product Overview

The 1650780000 is a 16-position heavy-duty Female Insert with screw connection. The HDC series insert made of PC glass-fiber reinforced (UL-listed and railway-certified). It is suitable for use with HA series rectangular power connectors.
  • 2.5mm² Conductor cross-section
  • <=2mR Volume resistance
  • 10¹⁰R Insulation resistance
  • >=500 Plugging cycles (silver)
  • 16A Rated current (DIN EN 61984)
  • 4kV Rated impulse voltage (DIN EN 61984)
  • 250V Rated voltage (DIN EN 61984)
  • UL94V-0 Flammability rating
  • -40 to 125°C Limit temperature range

Applications

Power Management

Product Information

Want to see similar products? Simply select your required attributes below and hit the button ×


:
HA Series

:
Cable Mount

:
Receptacle

:
16Contacts

:
Socket

:
2Rows

:
Screw

:
5

:
Copper

:
Silver Plated Contacts

Find similar products Choose and modify the attributes above to find similar products.

Technical Docs (2)

Also Known As

HDC HA 16 FS

4 In stock Need more?

4 available for 3 - 4 business days delivery

S$29.26 ( S$31.31  Inc. GST)
